Udor Diaphragm PumpsThe table below is a quick reference guide for Udor Diaphragm pumps and components. Pump, regulator, and gear reduction listings are linked to an exploded view that contains a break down of each part. To view the parts list just click on the link to open the PDF in a new window. To order Udor replacement parts give our parts department a call at 1-800-706-9530. Pump Diaphragm Kit Oil Cap. Valve Control Unit Repair Kit Gear Reduction Oil Cap. Kappa 15 8700.27 4 OZ 6006.11 N/A 8700.05 5047.D7 2 OZ Kappa 7/15/18 12V 8700.27 4 OZ 6006.11 N/A N/A N/A N/A Kappa 25 8700.65 12 OZ 6006.01 6010.95 6062.A9 5085.F7 3 OZ Kappa 30/40/50 8700.02 20 OZ 6006.01 6010.24 8701.10 5027.75 16 OZ Kappa 33/43/53 8700.45 20 OZ 6006.01 6010.93 6062.A9 5071.75 16 OZ Kappa 55 8700.26 32 OZ 6006.01 6010.24 8701.10 5027.75 16 OZ Kappa 75 8700.10 30 OZ 6006.01 6047.06 8701.02 5033.A4 16 OZ Kappa 100 8700.24 40 OZ 6006.01 6047.06 8701.02 5034.B5 28 OZ Kappa 120 8700.22 84 OZ 6006.08 6005.15 8701.03 5034.B5 28 OZ Kappa 150 8700.22 84 OZ 6006.08 6005.15 8701.03 5096.B5 28 OZ Iota 17 8700.01 7 OZ 6006.04 6010.23 8701.01 5028.79 3 OZ Iota 20 8700.01 7 OZ 6006.04 6010.23 8701.01 5094.76 3 OZ RO-70 8700.05 18 OZ 6006.08 6047.06/LP 8701.02 5027.75 16 OZ RO-110 8700.04 30 OZ 6006.08 SB-3 SB-3/KIT 5033.A4 16 OZ RO-110C/ 130C 8700.04 30 OZ 6006.08 SB-3 SB-3/KIT PTO PTO RO-160C/ 160CC 8700.09 44 OZ 6006.08 PTO PTO BETA-110CC 8700.06 87 OZ 6006.08 6005.15 8701.03 BETA-150CC 8700.07 87 OZ 6006.08 6005.15 8701.03 BETA-200CC/ 240CC 8700.55 160 OZ 6006.08 6005.14 8701.03 ZETA 40P/ 85P 8700.60 32 OZ 6006.36 6010.96 6062.A9 5027.75 16 OZ ZETA-85/100 8700.60 32 OZ 6006.36 6010.95 6062.A9 5027.75 16 OZ ZETA-85C/ 100C 8700.60 23 OZ 6006.34 N/A N/A Udor Spray GunsTo view the parts list for Udor spray guns click on the link below to open a PDF in a new window. Udor Turbo - Adjustable Spray Gun - 26.901.162 Udor Turbine - Adjustable Spray Gun - 7.901.103 Udor Long Range - Adjustable Spray Gun - 13.901.151 Udor Reference Material Udor Pump Service Guide Oil Guide Udor Torque Specs Udor Pump Trouble Shooting
